Cooler Master MCM-H500P-MGNN-S01 MasterCase Black ATX Mid-Tower PC Case w/ Front Mesh Ventilation, 2x 200mm RGB Fans

Cooler Master MasterCase H500P Mesh ARGB Mid‑Tower – High‑Airflow, Dual 200 mm RGB Front Fans

Elevate your PC build with the Cooler Master MasterCase H500P Mesh ARGB—a robust mid-tower case built for high performance and visual flair. Its full mesh front panel maximizes airflow to your core components while showcasing beauty through sleek ARGB fans and a tempered glass side panel. Equipped with dual 200 mm ARGB intake fans, this case pushes exceptional cooling at low noise, making it ideal for demanding gaming rigs and high-end builds.

This chassis accommodates everything from Mini‑ITX to E‑ATX motherboards, offers vertical GPU mounting, and supports large cooling setups—think 360 mm radiators in the front or top—all backed by smart cable management features like a PSU shroud and dust filters.

Specification

Specification Details

Model Number MCM‑H500P‑MGNN‑S01 (Gun Metal / Black)

Form Factor ATX Mid‑Tower; supports Mini‑ITX, Micro‑ATX, ATX, E‑ATX (up to 12" × 10.7")

Materials Steel, plastic, tempered glass, mesh

Dimensions 544 × 242 × 542 mm (21.4 × 9.5 × 21.3 in)

Weight ~11.3 kg

Front I/O 2× USB 3.2 Gen1, 2× USB 2.0, Audio In/Out, ARGB controller + 2‑to‑3 splitter

Pre‑installed Fans 2× 200 mm ARGB (front), 1× 140 mm rear (1200 RPM)

Fan Support Front: 3×120/140 mm or 2×200 mm; Top: same; Rear: 1×120/140 mm

Radiator Support Front/Top: up to 360 mm; Rear: up to 140 mm

GPU Clearance Up to 412 mm

CPU Cooler Clearance Up to 190 mm

PSU Clearance Up to 220 mm, bottom-mounted

Drive Bays Combo: 2× 3.5″ / 2.5″; plus 2× 2.5″ dedicated

Expansion Slots 7 standard + 2 vertical (requires riser cable)

Dust Filters Top, front, bottom
